Custom Bent Sheet Metal Spring Clip

Stamped & Sheet Metal Parts

Custom Bent Sheet Metal Spring Clip

Eight-station progressive die for a brass terminal, tooled in house with replaceable inserts so high-wear stations can be swapped on site.

MOQ: 500 pcs
Lead time: 15–25 days
Tolerance: ±0.05 mm

Material
Stainless steel 304 / SPCC
Process
Wire cutting, EDM, assembly
Tolerance
±0.05 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report

Request a quote

Material Options

Spring steel: High elasticity, durable repeated clamping
304 Stainless steel: Rust-resistant, for humid, high-temperature and food machinery
316 Stainless steel: For corrosive and coastal working conditions

Technical specification

Material
Stainless steel 304 / SPCC
Process
Wire cutting, EDM, assembly
Tolerance
±0.05 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report
Drawing format
STEP, DWG, PDF accepted
