Stamped Mounting Plate with Standoff Studs & Elongated Slots

Stamped & Sheet Metal Parts

Stamped Mounting Plate with Standoff Studs & Elongated Slots

0.8 mm perforated grille laser-cut from stainless sheet, hole pattern positioned to drawing and edges deburred before bending.

MOQ: 500 pcs
Lead time: 15–25 days
Tolerance: ±0.10 mm

Material
Stainless steel 304
Process
Fibre laser cutting, deburring
Tolerance
±0.10 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report

Request a quote

Material Options

304 Stainless Steel: Rust-resistant, ideal for humid, high-temperature and food-grade environments
316L Stainless Steel: Superior corrosion resistance for chemical, salty and aggressive media
Aluminum: Lightweight, good thermal conductivity for high-temperature air systems
Galvanized steel: Cost-effective for normal ventilation

Technical specification

Material
Stainless steel 304
Process
Fibre laser cutting, deburring
Tolerance
±0.10 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report
Drawing format
STEP, DWG, PDF accepted
