Stamped L-Shaped Mounting Bracket with Circular Cutout

Stamped & Sheet Metal Parts

Stamped L-Shaped Mounting Bracket with Circular Cutout

Multi-port manifold milled from solid aluminium, O-ring grooves and threaded ports finish-machined in one set-up for a reliable seal.

MOQ: 500 pcs
Lead time: 15–25 days
Tolerance: ±0.02 mm

Material
Aluminium 6061-T6
Process
CNC milling, drilling, tapping
Tolerance
±0.02 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report

Request a quote

Material Options

304 Stainless Steel: Rust-proof, suitable for humid, high-temperature and general industrial environments
316 Stainless Steel: For corrosive, coastal or chemical conditions
Galvanized cold rolled steel: Economical option for indoor dry applications

Technical specification

Material
Aluminium 6061-T6
Process
CNC milling, drilling, tapping
Tolerance
±0.02 mm
Surface finish
Deburred, optional powder coating
Inspection
CMM report + full dimensional report
Drawing format
STEP, DWG, PDF accepted
